제품 상세 정보:
|
| 애플리케이션: | EV 배터리 팩 BMS PCB 및 FPC용 컨포멀 코팅 | 경화 조건: | 1500mJ/cm²(UV) |
|---|---|---|---|
| 25C에서의 점도: | 450 ± 150mPa·s | 경도: | 73 쇼어 A |
| 색상: | 호박색 투명 | 유전 강도: | 23kV/mm |
| 특징: | 청색형광으로 검사가 용이하며 냄새가 적고 자극이 적습니다. | 보관상태: | 8~28°C에서 6개월 |
| 포장: | 1kg / 5kg | ||
| 강조하다: | UV cure adhesive for EV battery,Circuit board protection glue,Flexible printed circuits coating |
||
Circuit Board Protection Glue Description "Reliable protection, easy inspection." This circuit board protection glue (3200) is an amber transparent, solvent-free UV curing conformal coating specially developed for EV battery pack BMS boards and flexible printed circuits (FPC). It offers low hardness, low irritation and low odor for a friendly working environment, good adhesion to PCB substrates, plastics, glass and metal, and its blue fluorescence makes coating inspection
